D28 M11 H15 Double Layer Laser Cutting Nozzle for Han's Compatible Fiber Laser Cutting Head

D28 M11 H15 Double Layer Laser Cutting Nozzle

The D28-E-C-15 double layer laser cutting nozzle is designed for use with compatible Han's fiber laser cutting heads and CNC fiber laser cutting machines.

Featuring a 28 mm outer diameter, M11 threaded connection and 15 mm overall height, the nozzle provides a precise mechanical interface with the cutting head and supports controlled assist-gas delivery during fiber laser cutting.

The double layer construction is suitable for cutting applications where stable gas flow, nozzle concentricity and consistent cutting performance are important. Precision machining of the nozzle aperture and internal gas passage helps maintain proper gas distribution around the laser cutting zone.

This nozzle series is available in a wide range of apertures from Ø1.2 mm to Ø6.0 mm, allowing users to select the appropriate specification according to laser power, material type, sheet thickness, assist gas and actual cutting parameters.

The D28-E-C-15 nozzle can be supplied as a replacement laser consumable for compatible Han's cutting head configurations used in industrial sheet metal processing.

Key Features

Double Layer Nozzle Structure
The double layer design supports controlled assist-gas delivery in fiber laser cutting applications.

Han's Compatible Cutting Head Application
Designed for compatible Han's fiber laser cutting head configurations using the corresponding D28 M11 nozzle interface.

D28 / 28 mm Outer Diameter
The nozzle features a 28 mm outside diameter for compatible laser cutting head assemblies.

M11 Thread Connection
Precision-machined M11 threads provide secure installation and convenient replacement.

H15 / 15 mm Overall Height
The 15 mm overall height is designed to match corresponding fiber laser cutting head configurations.

Wide Aperture Selection
Available in multiple sizes from Ø1.2 mm to Ø6.0 mm for different cutting conditions.

Precision Machined Aperture
Accurate aperture geometry and concentricity help support stable assist-gas flow around the cutting area.

Easy Replacement
The threaded design allows convenient nozzle inspection and replacement during routine cutting head maintenance.

Technical Specifications

Available Nozzle Aperture Sizes

Selection Note: The correct nozzle aperture should be selected according to laser power, material type, sheet thickness, assist gas, cutting head configuration and actual cutting parameters.

Typical Applications

The D28 M11 H15 Han's compatible double layer laser nozzle is suitable for fiber laser cutting systems used in industrial sheet metal fabrication.

Typical applications include:

• Stainless steel laser cutting
• Carbon steel laser cutting
• Mild steel sheet cutting
• Galvanized steel cutting
• Aluminum sheet processing
• CNC fiber laser cutting
• Sheet metal fabrication
• Industrial laser cutting applications

Depending on the laser cutting system and process requirements, different nozzle apertures may be selected for cutting with oxygen, nitrogen or compressed air as the assist gas.

How to Select the Correct Laser Nozzle

Choosing the correct laser nozzle requires matching both the cutting head interface and the actual processing conditions.

Cutting Head Compatibility
Confirm that the cutting head uses the corresponding D28 outer diameter, M11 thread and H15 nozzle geometry.

Nozzle Aperture
Select the appropriate aperture according to material type, sheet thickness and cutting process.

Laser Power
Different laser power levels may require different nozzle aperture and gas-flow configurations.

Material and Thickness
Carbon steel, stainless steel, aluminum and other materials may require different cutting parameters.

Assist Gas
Oxygen, nitrogen and compressed air have different pressure and flow characteristics.

Cutting Parameters
Laser power, focal position, cutting speed and gas pressure should be considered together when selecting the nozzle.

If the exact nozzle specification is unknown, the existing nozzle model, dimensions, markings, product photos or cutting head model can be used for identification.

Product Advantages

Designed for Han's Compatible Cutting Heads
The D28-E-C-15 provides a specific nozzle option for compatible Han's fiber laser cutting systems.

Stable Assist-Gas Delivery
Precision-machined internal geometry helps support controlled gas flow during laser cutting.

Wide Aperture Range
Multiple nozzle sizes from Ø1.2 mm to Ø6.0 mm cover a broad range of sheet metal cutting requirements.

Accurate M11 Thread
The precision-threaded interface supports reliable installation and convenient replacement.

Double Layer Construction
The double layer configuration is suitable for cutting processes where gas-flow control and cutting consistency are important.

Consistent Dimensions
Controlled outer diameter, overall height, aperture and thread specifications help provide repeatable installation.

Manufacturing & Quality Control

Laser cutting nozzle accuracy is important because nozzle geometry can influence assist-gas distribution and process stability.

Quality control focuses on:

• Nozzle aperture accuracy
• Aperture concentricity
• M11 thread accuracy
• 28 mm outer diameter consistency
• 15 mm overall height accuracy
• Internal gas passage geometry
• Surface finish
• Batch-to-batch dimensional consistency

Each nozzle specification is manufactured to provide reliable installation and stable performance in compatible fiber laser cutting head applications.

Ordering Information

If the exact nozzle model is unknown, customers can provide the existing nozzle markings, dimensions, cutting head model, product photos or physical sample for identification.

Compatibility

This D28 M11 H15 double layer nozzle is designed for use with compatible Han's fiber laser cutting heads using the corresponding nozzle interface.

Please confirm the 28 mm outer diameter, M11 thread, 15 mm overall height, aperture size and cutting head model before ordering.

Compatibility can be checked according to the nozzle model, dimensions, cutting head model, photos or customer sample.
