Single V-Die V12 — 88°
$132.00
88° single V-die, 12 mm opening for air bending 1.5–2 mm sheet (8×T rule).
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
SKU: WYS-DV-1288Category: Press Brake V-Dies
Description
A hardened single V-die with a 12 mm opening, ideal for air bending thin sheet where the V should be roughly 8× material thickness.
Every WYS tool is precision-ground and induction-hardened for repeatable, high-accuracy bending and a long service life on hydraulic, servo-electric and CNC press brakes.
Key Features
- 12 mm V-opening tuned for 1.5–2 mm material
- Radiused, hardened die shoulders reduce marking
- 88° angle for accurate 90° air bends
- Standard bottom tang; fits most European holders
Technical Specifications
| Tool Type | Bottom V-die |
| Bending Method | Air bending |
| V-Opening | 12 mm |
| Angle | 88° |
| Shoulder Radius | R1.5 mm |
| Recommended Thickness | 1.5–2.0 mm |
| Max Load | 100 t/m |
| Material | 42CrMo alloy steel |
| Hardness | Induction-hardened HRC 48–52 |
| Origin | China |
Typical Applications
- Air bending thin mild steel and stainless
- Enclosures, brackets and light fabrication
- General job-shop bending
Segmented lengths, custom profiles, special radii and OEM-compatible shanks (Amada, Trumpf, LVD, Bystronic, Wila) are available on request. Contact us for a tailored quotation.
