4-Way Die Block (V10 / V16 / V20 / V25)
$268.00
Four V-openings machined on one block for rapid changeover of small jobs.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
SKU: WYS-DV-4WAYCategory: Press Brake V-Dies
Description
A four-way die block with V10, V16, V20 and V25 openings on its four faces — simply rotate to switch openings without swapping tools.
Every WYS tool is precision-ground and induction-hardened for repeatable, high-accuracy bending and a long service life on hydraulic, servo-electric and CNC press brakes.
Key Features
- Four openings: V10, V16, V20, V25
- Rotate-to-select for instant changeover
- Hardened shoulders on every face
- Ideal for prototyping and short runs
Technical Specifications
| Tool Type | 4-way die block |
| Bending Method | Air bending |
| V-Openings | 10 / 16 / 20 / 25 mm |
| Angle | 88° |
| Recommended Thickness | 1.2–4.0 mm |
| Max Load | 110 t/m |
| Material | 42CrMo alloy steel |
| Hardness | Induction-hardened HRC 48–52 |
| Origin | China |
Typical Applications
- Prototype and short-run job shops
- Frequent thickness changes
- Training and general-purpose bending
Segmented lengths, custom profiles, special radii and OEM-compatible shanks (Amada, Trumpf, LVD, Bystronic, Wila) are available on request. Contact us for a tailored quotation.
