Murata Wiedemann 114 Series XA Station Guide

Murata Wiedemann 114 Series XA Station Punch Guide

The Murata Wiedemann 114 Series XA Station Guide is an important component of the 114 Style punch press tooling system. It is designed for the XA station and works together with the corresponding punch tooling components to maintain accurate positioning and controlled movement during punching operations.

The guide provides mechanical support and guidance for the moving tooling components, helping maintain alignment during repeated punching cycles. Accurate guidance is particularly important for maintaining consistent punching quality, reducing unnecessary lateral movement and supporting stable tool operation.

This product is manufactured as a Murata Wiedemann Type replacement guide and can be supplied for tooling maintenance, replacement of worn components or assembly with other compatible 114 Series punch tooling.

Key Features

• Designed for 114 Series XA Station – Manufactured for the dimensional and installation requirements of compatible Murata Wiedemann 114 Style XA station tooling.
• Precision Guiding Function – Helps maintain accurate movement and alignment of the punch tooling during punching cycles.
• Stable Tooling Operation – Proper guide accuracy helps reduce unwanted lateral movement and contributes to consistent hole quality and tooling performance.
• Wear-Resistant Construction – Precision-machined working surfaces are designed for repeated industrial punching applications.
• Replacement Tooling Component – Suitable for replacing worn or damaged guides in existing Murata Wiedemann 114 punch press tooling assemblies.
• Precision Manufacturing – Critical dimensions and mating surfaces are accurately machined to support proper installation and reliable operation.
• Custom Manufacturing Available – WYS Machinery can manufacture compatible Murata Wiedemann punch tooling and replacement components according to customer drawings, samples or application requirements.

Technical Specifications

Function of the XA Station Guide

During CNC punching, accurate alignment between tooling components is essential. The 114 Series XA Station Guide helps maintain the correct movement and positioning of the punch tooling assembly.

A correctly manufactured guide can contribute to:

• stable punch movement;
• accurate tooling alignment;
• consistent punching quality;
• reduced unwanted lateral movement;
• reliable operation during repeated punching cycles;
• improved service performance of the complete punch tooling assembly.

For this reason, dimensional accuracy, concentricity, mating surfaces and manufacturing consistency are important considerations when selecting a replacement Murata Wiedemann 114 tooling guide.

Typical Applications

This XA Station Guide is suitable for:

• Murata Wiedemann 114 Style punch press tooling;
• XA station punch tooling assemblies;
• CNC turret punch press maintenance;
• replacement of worn punch guides;
• repair and rebuilding of existing 114 tooling assemblies;
• sheet metal punching production;
• customized Murata Wiedemann compatible punch tooling.

It can be supplied as an individual replacement component or together with other compatible tooling parts according to customer requirements.

Manufacturing Quality

WYS Machinery manufactures CNC punch press tooling with attention to dimensional accuracy, mating surfaces and repeatable assembly performance.

For replacement components such as the Murata Wiedemann 114 XA Station Guide, accurate machining is especially important because the guide directly influences the positioning and movement of the tooling assembly.

Each component can be manufactured according to the required tooling specification, customer drawing or physical sample.

Standard & Custom Murata Wiedemann Type Tooling

In addition to the 114 Series XA Station Guide, WYS Machinery can provide a range of compatible Murata Wiedemann Type punch press tooling, including punches, dies, guides, holders, strippers and related replacement components.

Standard punching shapes and customized tooling solutions can be manufactured according to the customer's sheet metal application.

For special requirements, customers can provide:

• machine model;
• tooling series;
• station;
• required component;
• punch shape and dimensions;
• sheet material;
• sheet thickness;
• drawings or tooling samples.

Our team can then recommend or manufacture a suitable tooling solution for the application.
