Murata Wiedemann 114 Series E/F Station Punch Guide

The Murata Wiedemann 114 Series E/F Station Guide is a precision tooling component developed for the E/F Station configuration of the 114 Series punch tooling system.

The guide forms part of the punch-side tooling assembly and provides controlled guidance for the associated tooling components throughout the punching cycle. Its dimensional accuracy and correct fit are important for maintaining stable movement, proper alignment and repeatable performance during sheet metal punching.

This model is specifically intended for the corresponding 114 Series E/F Station tooling configuration. Since Murata Wiedemann 114 tooling includes different guide designs for different stations, replacement components should always be selected according to the correct tooling series, station and guide structure.

Key Features

• 114 Series E/F Station Design – Designed for compatible Murata Wiedemann 114 Style E/F Station punch tooling.
• Station-Specific Guide Configuration – Manufactured according to the corresponding E/F Station tooling structure rather than as a universal guide for all 114 Series stations.
• Precision Punch Guidance – Provides controlled movement and guidance for associated punch-side tooling components.
• Stable Tool Alignment – Accurate guiding and mating surfaces help maintain the required positioning throughout repeated punching cycles.
• Precision-Machined Construction – Critical dimensions, mounting features and working surfaces are accurately manufactured for reliable component fit.
• Suitable for Tooling Maintenance – Can be used as a replacement component when servicing or rebuilding compatible E/F Station tooling assemblies.
• Individual Replacement Available – Customers can order the guide separately without replacing the complete punch tooling assembly when only the guide is required.
• Custom Manufacturing Available – Replacement guides and other Murata Wiedemann Type tooling components can be manufactured according to drawings, dimensions, samples or specific application requirements.

Technical Specifications

Guide Function in 114 Series E/F Station Tooling

The guide is responsible for supporting controlled movement of the associated punch tooling components during operation.

Throughout repeated punching cycles, accurate guide geometry helps maintain the required relationship between the moving components of the punch-side assembly.

A correctly matched and manufactured 114 Series E/F Station Guide can contribute to:

• controlled punch-side movement;
• stable tooling alignment;
• repeatable punching cycles;
• consistent tooling operation;
• reduced unwanted lateral movement;
• reliable interaction between mating tooling components.

The condition of the guide should therefore be considered when inspecting an existing punch tooling assembly for wear or loss of accuracy.

Replacement E/F Station Guide

Customers do not necessarily need to replace a complete tooling assembly when an individual guide requires replacement.

WYS Machinery can supply the Murata Wiedemann 114 E/F Station Guide separately for maintenance and tooling rebuild applications.

Because different stations and tooling configurations can use different guide structures, accurate identification is important before manufacturing a replacement component.

Customers can provide:

• tooling series;
• station information;
• existing guide dimensions;
• photographs of the existing tooling;
• technical drawings;
• physical tooling samples.

This information helps us identify or manufacture the appropriate replacement guide for the application.

Typical Applications

The Murata Wiedemann 114 Series E/F Station Guide is suitable for:

• Murata Wiedemann 114 Style tooling systems;
• 114 Series E/F Station punch tooling;
• CNC turret punch press applications;
• sheet metal punching production;
• punch tooling maintenance;
• replacement of worn E/F Station guides;
• rebuilding existing punch tooling assemblies;
• custom punch and die tooling projects.

The guide can be supplied individually or together with other compatible tooling components according to customer requirements.

Manufacturing Quality

Guide components require accurate dimensional control because their guiding and mating surfaces directly influence movement within the punch tooling assembly.

WYS Machinery focuses on precision machining of critical dimensions, guiding surfaces, mounting positions and mating features when manufacturing Murata Wiedemann Type replacement tooling.

For non-standard or difficult-to-identify tooling, production can also be based on customer drawings or physical samples.

Standard & Custom Murata Wiedemann Type Tooling

WYS Machinery supplies Murata Wiedemann Type punch press tooling and replacement components for sheet metal fabrication applications.

Our product range can include compatible punches, dies, guides and related tooling components for different stations and punching requirements.

For standard tooling, customers can provide the tooling series, station and required component information.

For customized punching applications, customers can send their finished sheet metal part drawings together with information about material type and thickness. Our team can assist with tooling selection and develop a suitable punch and die solution according to the actual punching requirement.

Replacement components can also be manufactured from customer-provided drawings or samples, providing an additional solution for maintenance of existing punch tooling.
