V12 30° Single-V Press Brake Lower Die for Acute-Angle Bending

This V12 30° press brake lower die uses a single-V structure for sheet metal applications requiring a narrow 30° forming groove.

The illustrated configuration features a 12 mm V-opening, 30° die angle, 90 mm overall height, 75 mm effective height, 25 mm overall width and 19 mm load-bearing section width, with a rated load capacity of 40 ton/m.

The combination of a V12 opening and 30° V-groove makes this lower die suitable for acute-angle air bending, pre-bending and multi-stage forming operations. Compared with smaller V-opening 30° dies, the V12 opening provides additional forming clearance while retaining the narrow angular geometry required for acute forming.

30° V-Groove for Very Acute Forming

The 30° die angle is intended for bending processes that require significantly more angular clearance than conventional 60°, 85°, 88° or 90° lower dies.

Typical applications include:

• Very acute-angle sheet metal bending
• Acute-angle air bending
• Pre-bending operations
• Multi-stage forming
• Precision flange bending
• Hemming preparation
• Components requiring springback allowance
• Custom sheet metal forming

The final tooling specification should be selected according to the material grade, sheet thickness, required bending angle, inside radius and workpiece geometry.

V12 Single-V Geometry

The illustrated die combines a 12 mm V-opening with a compact 25 mm overall profile.

Main dimensions include:

• V12 / 12 mm V-opening
• 30° die angle
• 90 mm overall height
• 75 mm effective height
• 25 mm overall width
• 19 mm load-bearing section width
• 13.5 mm bottom mounting width
• Approx. R1.5 shoulder radius
• Approx. R1 V-bottom radius
• 40 ton/m rated load capacity

The die angle, effective height, shoulder geometry, edge dimensions and mounting profile can all be customized according to the required bending application.

Custom Effective Tool Height

The illustrated configuration has an effective working height of 75 mm.

The effective height is not limited to this dimension. WYS Machinery can manufacture different effective heights according to the customer's:

• Press brake configuration
• Upper tooling height
• Machine daylight
• Clamping system
• Existing tooling combination

The overall height and effective working height can therefore be coordinated with the customer's complete press brake tooling setup.

Key Features

• Single-V lower die structure
• V12 / 12 mm V-opening
• 30° acute-angle V-groove
• 90 mm overall height
• 75 mm effective height
• 25 mm overall width
• 19 mm load-bearing section width
• 13.5 mm bottom mounting width
• 40 ton/m rated load capacity
• Approx. R1.5 shoulder radius
• Approx. R1 V-bottom radius
• Suitable for acute-angle bending
• Suitable for pre-bending
• Suitable for multi-stage forming
• Greater forming clearance than smaller 30° V-openings
• Custom V-openings available
• Custom die angles available
• Custom effective heights available
• Custom edge geometry available
• Custom tool lengths and segmentation available
• Custom mounting systems available

Technical Specifications

Typical Applications

This V12 30° single-V press brake lower die can be used for:

• Acute-angle sheet metal bending
• Very acute-angle air bending
• Pre-bending operations
• Multi-stage bending
• Hemming preparation
• Precision flange forming
• Stainless steel sheet bending
• Mild steel sheet bending
• Electrical enclosure production
• Sheet metal cabinet manufacturing
• Machinery components
• Customized sheet metal forming

The appropriate tooling specification should be selected according to the sheet thickness, material properties, required inside radius, flange dimension, bend angle and required forming force.

Standard & Custom Options

The V12 30° lower die shown on this page represents one available configuration only.

WYS Machinery can customize:

• V-opening
• Die angle
• Overall height
• Effective height
• Overall width
• Load-bearing section width
• Shoulder radius
• V-bottom radius
• Edge geometry
• Tool length
• Segmented length
• Bottom mounting profile
• Positioning structure
• Clamping interface

We can also manufacture single-V, double-V, multi-V and special-purpose lower dies according to different sheet metal bending requirements.

Compatible Press Brake Tooling Systems

WYS Machinery manufactures lower dies for different press brake brands, tooling standards and clamping systems.

Available configurations include:

TRUMPF Type, WILA Type, LVD Type, Bystronic Type, Amada / Promecam Type, European Type and other customized press brake tooling systems.

The lower-die mounting structure shown in the drawing is only one reference configuration.

The bottom mounting profile, positioning geometry, overall height, effective height and complete die cross-section can all be adapted to the customer's press brake.

Customers can provide a machine model, existing tooling drawing, lower die cross-section, tooling sample or workpiece drawing for technical evaluation.

Custom V-Opening, Angle and Geometry

The V12 opening and 30° angle shown here are not fixed limitations.

Different V-openings and die angles can be manufactured according to:

• Material grade
• Sheet thickness
• Required bending angle
• Required inside radius
• Minimum flange dimension
• Material springback
• Required forming force
• Press brake configuration

The shoulder radius, V-bottom radius and surrounding edge geometry can also be customized as part of the complete tooling solution.

Custom Press Brake Tooling Design Service

Customers who are unsure which lower die specification is suitable can provide their:

workpiece drawing, material grade, sheet thickness, required bend angle and press brake model.

Our engineering team can evaluate the forming requirement and recommend an appropriate combination of:

V-opening + die angle + height + radius + load-bearing geometry + mounting interface.

The tooling can then be manufactured according to the actual workpiece and machine configuration.

Why Choose WYS Machinery

WYS Machinery manufactures standard and customized press brake punches, lower dies and sheet metal bending tooling for different forming requirements.

Our lower tooling capabilities include:

• Single-V press brake dies
• Double-V dies
• Multi-V dies
• 30° acute-angle lower dies
• 35° acute-angle lower dies
• 60° lower dies
• 85° and 88° lower dies
• Small and medium V-opening dies
• Segmented tooling
• Customized tooling heights
• Custom mounting profiles
• Special lower die geometries
• Tooling designed according to customer workpiece drawings

The dimensions shown in our drawings are reference configurations. Height, width, V-opening, angle, radius, length and mounting structure can all be customized according to the customer's actual bending application.
