WYS 85° High-Profile Bystronic-Type Gooseneck Punch, H250 mm, R3
This 85° high-profile Bystronic-type gooseneck punch has an overall height of 250 mm, a total width of 60 mm, a 10 mm tip width and an R3 tip radius. With a maximum load capacity of 100 ton/m, its extra-tall body is suitable for bending large and high-sided workpieces, while the recessed inner profile provides additional clearance during complex bending operations.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
The WYS 85° high-profile Bystronic-type gooseneck punch is designed for bending large, tall and complex sheet-metal components. Its 250 mm overall height provides extended working reach, making it suitable for applications where a standard-height upper tool may not offer sufficient space.
The recessed inner profile creates additional clearance between the punch body and the formed workpiece. This helps reduce interference when bending deep boxes, tall flanges and complex profiles, especially during multiple bending operations.
With a 60 mm total width, 10 mm tip width and R3 tip radius, the punch combines a spacious clearance profile with a strong working section. Its maximum load capacity of 100 ton/m supports stable performance in demanding sheet-metal bending applications.
Manufactured from high-strength 42CrMo alloy steel and precision-machined for accurate alignment, this upper tool is designed for compatible Bystronic-type press brake tooling and clamping systems. Custom heights, widths, angles, tip radii, clearance profiles and sectional lengths are available according to customers’ bending requirements.
Key Features
- High-profile Bystronic-type gooseneck punch
- Extra-tall 250 mm profile for large and high-sided workpieces
- Recessed inner geometry provides additional bending clearance
- Gooseneck profile helps reduce tool-to-workpiece interference
- Maximum load capacity of 100 ton/m
- 85° working angle suitable for controlled air bending
- R3 tip radius provides a strong and durable working nose
- 10 mm tip width supports stable load transmission
- 60 mm overall width provides structural strength and clearance
- Manufactured from high-strength 42CrMo alloy steel
- Precision-machined mounting profile for reliable alignment
- Custom profiles and segmented lengths available
Technical Specifications
| Specification | Details |
|---|---|
| Tool Type | High-Profile Gooseneck Punch / Upper Tool |
| Tooling Style | Bystronic-Type Press Brake Tooling |
| Punch Angle | 85° |
| Tip Radius | R3 |
| Overall Height | 250 mm |
| Total Tool Width | 60 mm |
| Tip Width | 10 mm |
| Maximum Load | 100 ton/m |
| Material | 42CrMo Alloy Steel |
| Hardness | HRC54 ± 2 |
| Main Advantage | Extra working height and internal clearance |
| Customization | Angle, radius, height, width, clearance profile and sectional length |
Typical Applications
- Bending large sheet-metal workpieces
- Forming deep boxes, cabinets and industrial enclosures
- Producing components with tall sidewalls or return flanges
- Bending complex profiles that require additional inner clearance
- Multiple bending operations with a risk of workpiece interference
- General air bending on compatible Bystronic-type press brakes
- Hydraulic, CNC and servo-electric press brake applications
- Medium- and heavy-duty bending within the rated 100 ton/m capacity
Product Details / Manufacturing Quality
The 250 mm overall height gives this punch greater working reach than a standard-height upper tool. It is particularly suitable for large workpieces, deep components and products with high sidewalls.
Its recessed inner contour provides valuable relief space during successive bending operations. This allows the formed flange to pass around the punch body more easily, helping reduce the possibility of collision and expanding the range of profiles that can be produced.
The 10 mm tip width creates a strong load-bearing section, while the R3 tip radius improves nose durability and helps form a controlled internal bend radius. With a rated maximum load of 100 ton/m, the punch offers dependable strength for demanding industrial bending operations.
The tool is manufactured from 42CrMo alloy steel, providing a suitable combination of strength, toughness and resistance to deformation. Precision machining and controlled heat treatment help maintain accurate geometry, reliable mounting and consistent bending performance throughout long-term production.
Standard & Custom Press Brake Tooling
WYS manufactures standard and custom press brake punches, dies, gooseneck punches, radius tools, hemming tools, adapters and special forming tools for various press brake systems.
We provide a free tooling design service. Customers can send us their finished-part drawings, sheet thickness, material grade and press brake specifications. Our engineering team will evaluate the bending sequence, workpiece clearance and required load before recommending a suitable tooling solution.
The overall height, tool width, punch angle, tip radius, tip width, gooseneck clearance and sectional arrangement can all be customized. Continuous tools and segmented sets are available according to different production requirements.
This product is manufactured by WYS for compatible Bystronic-type tooling and clamping systems. WYS is an independent press brake tooling manufacturer, and no official affiliation with the referenced machine brand is implied.
