97mm Split-Type Interchangeable Press Brake Punch Holder – 100 Ton/m
The 97mm split-type interchangeable press brake punch holder is a reusable upper tooling body designed for use with different replaceable punch inserts. With a 67mm effective height and 100 ton/m load capacity, the same holder can be combined with radius, standard-angle or custom punch inserts, helping reduce tooling cost while increasing flexibility for different sheet metal bending applications. Custom holder dimensions, structures and press brake interfaces are available according to customer requirements.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
Split-Type Interchangeable Press Brake Punch Holder
This split-type interchangeable press brake punch holder is designed as the reusable body of a modular upper tooling system.
Unlike a conventional one-piece press brake punch, the holder and working punch insert are manufactured as separate components. The same holder can therefore be combined with different replaceable punch inserts for different bending profiles.
The model shown has a total height of 97 mm, an effective height of 67 mm, a holder width of 14 mm, and a load capacity of 100 ton/m.
Reusable Holder with Replaceable Punch Inserts
The main advantage of this modular design is that the punch holder can be reused while only the working insert is changed.
When a different bending radius, angle or profile is required, the operator can install another compatible punch insert instead of replacing the complete upper tool.
Compatible inserts may include:
- Radius punch inserts
- Standard-angle punch inserts
- Acute-angle punch inserts
- Special-profile inserts
- Custom forming inserts
This design is particularly useful for manufacturers producing multiple sheet metal parts or frequently changing bending profiles.
By reusing the same punch holder, the number of complete punches required can be reduced, helping lower tooling investment and simplify tooling management.
Key Features
- Split-type modular upper tooling design
- Reusable press brake punch holder
- Compatible with different replaceable punch inserts
- 97 mm total height
- 67 mm effective height
- 14 mm holder width
- 100 ton/m load capacity
- Suitable for radius, standard and special-profile inserts
- Helps reduce complete tooling replacement cost
- Holder dimensions and structure can be customized
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Split-Type Interchangeable Press Brake Punch Holder |
| Tool Position | Upper Tool / Punch |
| Total Height | 97 mm |
| Effective Height | 67 mm |
| Holder Width | 14 mm |
| Load Capacity | 100 ton/m |
| Structure | Reusable Holder + Replaceable Punch Insert |
| Compatible Inserts | Radius, Standard-Angle and Custom Inserts |
| Holder Height | Customizable |
| Holder Width | Customizable |
| Holder Structure | Customizable |
| Insert Interface | Customizable |
| Press Brake Interface | Customizable |
Typical Applications
This interchangeable punch holder is suitable for press brake bending operations where multiple punch profiles are required on the same machine.
Typical applications include:
- Different-radius bending
- Standard sheet metal bending
- Custom profile bending
- Prototype production
- Small-batch sheet metal manufacturing
- Frequent tooling change applications
- Customized forming operations
The modular structure is especially useful when several punch inserts can share the same holder body and machine connection interface.
Manufacturing & Design Advantages
The punch holder and punch insert are designed as separate functional components.
This modular construction allows the holder to remain in service while the working insert is replaced according to the required bending profile.
For customers using multiple punch geometries, this approach can reduce the need to manufacture a complete upper punch for every application.
It can also simplify spare tooling preparation because only the working insert may need to be changed when a different radius or profile is required.
For customized applications, the holder-to-insert connection can be designed according to the required load, tool geometry and press brake configuration.
Standard & Custom Options
The dimensions shown on this page represent one available configuration and do not define the manufacturing limit of WYS Machinery.
The following parameters can be customized:
- Total holder height
- Effective height
- Holder width
- Holder cross-section
- Insert connection structure
- Punch insert profile
- Working radius
- Working angle
- Load capacity
- Press brake mounting interface
Custom versions can be manufactured for AMADA, Trumpf-type, WILA-type, LVD-type, Bystronic-type and other press brake tooling systems.
Customers can provide the workpiece drawing, material thickness, required bending profile and press brake information. WYS Machinery can design a suitable holder and interchangeable punch insert combination according to the actual bending requirement.
