WILA Type 80° Press Brake Punch – H98mm, R1, 100 Ton/m
This WILA Type 80° press brake punch features a 98 mm working height, R1 mm tip radius and 100 ton/m maximum load capacity. Its 80° acute-angle profile is suitable for precision air bending, acute pre-bending and applications requiring springback compensation. Manufactured from high-strength 42CrMo tool steel and hardened to HRC54±2, it provides reliable accuracy, wear resistance and long service life.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
This WILA Type 80° press brake punch is a precision upper tool developed for general sheet metal bending and acute-angle forming applications. Its straight punch profile provides stable force transmission, while the 25 mm tool width and 10 mm tip width create a robust working section capable of handling loads up to 100 ton/m.
The 80° punch angle allows the sheet to be bent slightly beyond 90°, making the tool particularly useful when material springback must be compensated. It can also be used for acute-angle pre-bending and other forming operations when paired with a suitable lower V-die.
With a working height of 98 mm and an R1 mm tip radius, this upper punch combines compact dimensions, precise bend-line control and dependable load-bearing performance. The tool is manufactured from 42CrMo alloy tool steel and hardened to HRC54±2 for enhanced wear resistance and consistent bending accuracy.
Key Features
- WILA Type upper punch profile for compatible press brake clamping systems
- 80° acute-angle tip for air bending and springback compensation
- Compact 98 mm working height for general-purpose bending
- R1 mm tip radius for accurate bend-line formation
- 25 mm overall tool width with a reinforced 10 mm tip section
- Maximum load capacity of 100 ton/m
- Manufactured from high-strength 42CrMo alloy tool steel
- Hardened to HRC54±2 for improved wear resistance
- Precision-ground working surfaces for consistent bending results
- Available in full-length or segmented configurations
- Custom dimensions, angles, radii and tool lengths are available
Technical Specifications
| Parameter | Specification |
|---|---|
| Tool Type | WILA Type Press Brake Upper Punch |
| Punch Profile | Straight Punch |
| Working Height (H) | 98 mm |
| Overall Width | 25 mm |
| Upper Clamping Section Width | 20 mm |
| Tip Width | 10 mm |
| Tip Angle (α) | 80° |
| Tip Radius (R) | 1 mm |
| Maximum Load | 100 ton/m |
| Material | 42CrMo |
| Hardness | HRC54±2 |
| Length | Continuous or segmented, customizable |
| Application | Air bending, acute bending and pre-bending |
Typical Applications
This WILA Type acute-angle punch is suitable for:
- Precision air bending of mild steel, stainless steel and aluminium sheet
- Producing bends that require compensation for material springback
- Acute-angle bending and pre-bending before secondary forming
- General sheet metal fabrication
- Electrical cabinets and control enclosures
- Machinery covers and industrial panels
- HVAC ducts and ventilation components
- Metal furniture and architectural sheet metal parts
- Batch production requiring consistent bend angles and repeatability
- CNC hydraulic and servo-electric press brake applications
The punch should be paired with a lower die whose V-opening, die angle and load capacity are appropriate for the material type, sheet thickness and required inside bend radius.
Product Details and Manufacturing Quality
The punch is manufactured from selected 42CrMo alloy steel to provide a reliable balance of strength, toughness and fatigue resistance. Its working areas are precision machined and hardened to HRC54±2, helping reduce premature wear during repeated bending operations.
Accurate control of the 80° tip profile and R1 mm radius supports stable bend-line positioning and consistent forming results. The reinforced 10 mm tip section improves load-bearing capability while retaining the advantages of an acute-angle press brake punch.
Depending on the customer’s press brake configuration, the tooling can be supplied in standard full lengths, customized continuous lengths or segmented sets. Section lengths and horn pieces can be designed according to the required bending sequence and workpiece geometry.
Standard and Custom WILA Type Press Brake Tooling
WYS Machinery supplies standard and customized WILA Type press brake punches, lower dies, adapters and tooling accessories for compatible clamping systems.
Customers can send us their workpiece drawings, material specifications and bending requirements. Our team provides a free tooling design service and recommends an appropriate combination of upper punch and lower die.
Available customization options include:
- Working height and overall width
- Punch angle and tip radius
- Tip width and relief profile
- Tool length and segmentation arrangement
- Special clearance geometry
- Load capacity
- Surface blackening or protective coating
- Tooling solutions for special profiles and complex workpieces
This product is manufactured as WILA Type compatible press brake tooling and is not presented as an original WILA-manufactured product or as evidence of official brand affiliation.
