Standard 90° R1 Press Brake Upper Tool – 97 mm, 6 mm Tip

The WYS standard 90° R1 press brake upper tool is a versatile upper punch designed for general sheet metal air bending and industrial metal fabrication. Featuring a 90° punch angle, 97 mm overall height, 27 mm tool width, 6 mm tip width, and a R1 mm tip radius, this upper tool provides a practical solution for a wide range of sheet metal bending applications.

The tool features a reinforced load-bearing section designed to provide greater support in the working area and accommodate higher bending forces. With a maximum load capacity of 90 ton/m, it is suitable for general and medium-duty bending operations where reliable tooling strength and dimensional stability are required.

Manufactured from 42CrMo alloy steel and precision-machined for dimensional consistency, the tool is hardened to HRC 54 ± 2 to provide excellent wear resistance, strength, and long service life. The R1 mm tip radius provides a relatively sharper bending edge for applications requiring a smaller inside bend radius, when used with a suitable lower die and appropriate bending parameters.

Key Features

• 90° standard punch angle for general-purpose sheet metal bending

• R1 mm tip radius for applications requiring a smaller inside bend radius

• 6 mm tip width for a practical and versatile bending configuration

• Reinforced load-bearing section for improved support under higher bending forces

• 97 mm overall height for conventional press brake tooling applications

• 27 mm tool width with a standard and practical tool configuration

• Made from 42CrMo alloy steel for high strength and durability

• HRC 54 ± 2 hardness for improved wear resistance and extended service life

• 90 ton/m maximum load capacity for demanding bending applications

• Precision-machined working surfaces for accurate and repeatable bending

• Suitable for conventional and CNC press brake machines

• Standard tooling available, with custom configurations available on request

Technical Specifications

Typical Applications

• General sheet metal air bending for mild steel and other commonly processed sheet metal materials

• Cabinet, enclosure, electrical panel, and ductwork fabrication

• General industrial sheet metal fabrication, metal forming, and manufacturing applications

• Applications requiring a smaller inside bend radius with an R1 mm punch tip

• Suitable for workshops using Amada, LVD, Bystronic, and other compatible press brake machines

• Compatible tooling solutions available for major press brake systems, including Amada, TRUMPF, LVD, Bystronic, and WILA, subject to the required machine and tooling configuration

Segmented lengths, custom profiles, special tip radii, reinforced configurations, and OEM-compatible shanks are available on request. Contact WYS Machinery for a tailored press brake tooling solution and quotation.

Product Details & Manufacturing Quality

Each WYS press brake upper tool is manufactured with controlled dimensions and precision-machined working surfaces to ensure reliable tooling performance and consistent bending accuracy.

The use of 42CrMo alloy steel combined with HRC 54 ± 2 hardness provides an excellent balance of strength, wear resistance, and service life for regular industrial production. The reinforced load-bearing section provides additional structural support in the working area, making this configuration suitable for applications requiring a higher load capacity.

The R1 mm tip radius and 6 mm tip width provide a sharper working configuration for applications where a smaller inside bend radius is required. The actual achievable bend radius and angle depend on the material, thickness, lower die opening, machine capacity, and bending parameters.

With a 90 ton/m maximum load capacity, this upper punch is designed for demanding bending applications when used within the appropriate machine capacity and tooling configuration.

Standard & Custom Press Brake Tooling

In addition to standard press brake punches, WYS Machinery manufactures custom press brake tooling according to customer drawings, samples, machine specifications, or specific bending requirements.

Customized options may include different punch angles, tip widths, tip radii, load-bearing configurations, overall dimensions, lengths, profiles, shank configurations, and special tooling designs. OEM-compatible tooling solutions are also available for specific press brake machines and tooling systems.

Whether you need a standard upper punch for general sheet metal bending or a reinforced tooling solution for higher-load applications, WYS Machinery can provide precision press brake tooling tailored to your machine and production requirements.

Contact WYS Machinery for press brake tooling recommendations, technical support, compatibility confirmation, and a quotation.
