Bystronic-Type Sectional Punch Holder H140 × 20 mm – 80 Ton/m
Bystronic-type sectional punch holder for modular press brake upper tooling. Its 140 mm height and 20 mm-wide mounting profile provide a rigid connection between the machine clamping system and interchangeable punch inserts. Maximum load: 80 ton/m.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
Bystronic-Type Sectional Punch Holder
This WYS sectional Punch Holder is designed for Bystronic-type press brake tooling systems. It connects the upper clamping system with a compatible Replaceable Punch Insert, allowing different insert profiles to be installed without replacing the complete holder.
Its modular construction simplifies tooling replacement and provides greater flexibility for different bending profiles and customized applications.
Key Features
Bystronic-type sectional tooling structure
Designed for compatible Replaceable Punch Inserts
Stable connection between the clamping system and punch insert
Overall height: 140 mm
Upper width: 20 mm
Lower interface thickness: 14 mm
Maximum allowable load: 80 ton/m
Section lengths and interface details can be customized
Typical Applications
This Punch Holder is suitable for modular press brake tooling assemblies, replacement tooling projects and bending applications requiring interchangeable upper tool inserts.
WYS can manufacture compatible Replaceable Punch Inserts and complete sectional tooling assemblies according to customer drawings, bending requirements and press brake configurations.
Frequently Asked Questions
What is a sectional press brake Punch Holder?
A sectional press brake Punch Holder connects the machine’s upper clamping system with a compatible Replaceable Punch Insert. Different insert profiles can be installed while retaining the same holder.
What are the dimensions of this Punch Holder?
This Bystronic-type Punch Holder has an overall height of 140 mm, an upper width of 20 mm and a lower interface thickness of 14 mm. Its maximum allowable load is 80 ton/m.
Can WYS manufacture matching punch inserts?
Yes. WYS can manufacture compatible Replaceable Punch Inserts and complete sectional tooling assemblies based on customer drawings, bending requirements and press brake configurations.
WYS is an independent tooling manufacturer. This product is designed for compatible Bystronic-type press brake systems and is not manufactured or authorized by Bystronic.
