WYS 30° V6 Bystronic-Type Single-V Die, H120 mm
This Bystronic-type single-V lower die features a 6 mm V-opening, 30° groove angle, 120 mm overall height and 100 mm effective working height. With a maximum load capacity of 40 ton/m, the narrow V6 opening is suitable for precision bending of thin sheet metal, small flanges and acute-angle profiles.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
The WYS 30° V6 Bystronic-type single-V die is a precision lower tool designed for thin-sheet bending and acute-angle forming. It has a 120 mm overall height, a 100 mm effective working height, a 6 mm V-opening and a maximum load capacity of 40 ton/m.
The narrow V6 opening provides concentrated bending support and is particularly suitable for producing small bend radii and short flanges in thin sheet metal. Its 30° die angle allows the workpiece to be formed beyond 90°, making the die suitable for acute bending, springback compensation and pre-bending before a subsequent hemming operation.
The tall and slim die profile provides additional working height while maintaining access for narrow or complex components. Manufactured from high-strength 42CrMo alloy steel, the tool is precision-machined and heat-treated for consistent V-opening geometry, stable mounting and repeatable bending performance.
Key Features
- Bystronic-type single-V press brake die
- Narrow 6 mm V-opening, commonly designated V6
- 30° groove angle for acute-angle bending
- 120 mm overall height
- 100 mm effective working height
- Maximum load capacity of 40 ton/m
- Suitable for precision bending of thin sheet metal
- Helps produce small bend radii and short flanges
- Suitable for overbending and springback compensation
- Can be used for pre-bending before flattening or hemming
- Precision-machined V-opening for consistent bending results
- Manufactured from high-strength 42CrMo alloy steel
- Custom V-openings, angles, heights and segmented lengths available
Technical Specifications
| Specification | Details |
|---|---|
| Tool Type | Single-V Die / Lower Tool |
| Tooling Style | Bystronic-Type Press Brake Tooling |
| V-Opening | V6 / 6 mm |
| Die Angle | 30° |
| Overall Height | 120 mm |
| Effective Working Height | 100 mm |
| Maximum Load | 40 ton/m |
| Material | 42CrMo Alloy Steel |
| Hardness | HRC54 ± 2 |
| Main Advantage | Narrow V-opening for thin-sheet and acute-angle bending |
| Customization | V-opening, angle, height, mounting profile and sectional length |
Typical Applications
- Precision air bending of thin sheet metal
- Forming small internal bend radii
- Producing components with short flange dimensions
- Acute-angle bending and overbending
- Compensation for material springback
- Pre-bending before flattening or hemming
- Electrical enclosures, cabinets and precision sheet-metal parts
- Stainless steel, mild steel and aluminum fabrication
- Use on compatible Bystronic-type hydraulic, CNC and servo-electric press brakes
The appropriate sheet thickness and bending capacity depend on the workpiece material, tensile strength, punch radius, bending length and forming method. The calculated force must remain within the rated 40 ton/m capacity of the die.
Product Details / Manufacturing Quality
The 6 mm V-opening makes this die particularly suitable for thin sheet metal and applications requiring a relatively small bend radius. Compared with a wider V-die, the narrow groove provides better support for small workpieces and enables shorter minimum flange dimensions.
Its 30° groove angle provides sufficient space for acute-angle forming. It can be used to overbend the material to compensate for springback or to create a pre-bend before a separate flattening or hemming operation.
The die has an overall height of 120 mm and an effective working height of 100 mm. Its elevated working surface can help maintain a suitable bending setup when used with compatible punches and press brake configurations.
Manufactured from 42CrMo alloy steel, the die provides strength, toughness and resistance to deformation. Precision machining and controlled heat treatment help maintain accurate groove geometry, consistent tool alignment and repeatable bend angles during long-term production.
Standard & Custom Press Brake Tooling
WYS manufactures standard and custom single-V dies, multi-V dies, straight punches, gooseneck punches, acute-angle tools, hemming tools, adapters and special forming tools for different press brake systems.
The V-opening, groove angle, overall height, effective height, mounting profile and sectional arrangement can be customized. Optional black oxide surface treatment, continuous lengths and segmented tooling sets are available according to customer requirements.
WYS also provides a free tooling design service. Customers can send us their finished-part drawings, sheet thickness, material grade, bending length and press brake specifications. Our engineering team will evaluate the required V-opening, punch radius, bending force and forming sequence before recommending a suitable tooling solution.
This product is manufactured by WYS for compatible Bystronic-type tooling and clamping systems. WYS is an independent press brake tooling manufacturer, and no official affiliation with the referenced machine brand is implied.
