V16 30° Single-V Press Brake Lower Die for Acute-Angle Forming

This V16 30° press brake lower die uses a single-V structure designed for sheet metal forming applications requiring a sharp acute-angle groove with increased forming clearance.

The illustrated configuration features a 16 mm V-opening, 30° die angle, 90 mm overall height, 75 mm effective height and 25 mm body width, with a rated load capacity of 55 ton/m.

In this configuration, the 25 mm body width also forms the main load-bearing section, providing a solid supporting structure around the V-groove during bending.

The combination of a V16 opening and 30° V-groove makes this lower die suitable for very acute-angle air bending, pre-bending and multi-stage forming operations.

Compared with smaller 30° V-opening dies, the V16 opening provides additional forming clearance and can accommodate applications requiring a larger bending radius or broader workpiece geometry.

30° V-Groove for Very Acute-Angle Bending

The 30° groove angle is suitable for applications where the workpiece needs to be formed to a very acute intermediate angle.

Typical forming requirements can include:

• Very acute-angle air bending
• Pre-bending
• Multi-stage forming
• Hemming preparation
• Sharp flange forming
• Forming with springback allowance
• Customized sheet metal profiles

Tooling geometry should be selected according to the material, thickness, required bending angle, inside radius, flange geometry and forming sequence.

V16 Opening for Increased Forming Clearance

The 16 mm V-opening offers greater forming clearance than smaller V8, V10 or V12 openings in the same acute-angle tooling family.

This makes the V16 configuration suitable where a sharp 30° die geometry is still required but the workpiece needs more clearance through the forming zone.

Different V-openings can be manufactured according to the required bend radius, material thickness and workpiece geometry.

Full-Width Load-Bearing Structure

For this configuration, the 25 mm body width is also the main load-bearing section width.

This means the supporting body beneath the V-groove maintains a full-width structural section rather than using a narrower working section within a wider body.

The body width and supporting geometry can also be modified according to the required load, machine configuration and tooling interface.

Custom Effective Tool Height

The illustrated lower die has an overall height of 90 mm and an effective height of 75 mm.

The effective working height is not limited to 75 mm. WYS Machinery can customize it according to the customer's:

• Press brake configuration
• Upper tooling combination
• Machine daylight
• Clamping system
• Existing lower tooling
• Required working height

The lower die can therefore be designed as part of a complete tooling system rather than being restricted to the dimensions shown in the drawing.

Key Features

• Single-V lower die structure
• V16 / 16 mm V-opening
• 30° very acute-angle groove
• 90 mm overall height
• 75 mm effective height
• 25 mm body width
• 25 mm load-bearing section width
• 13.5 mm bottom mounting width
• Approx. R1.5 radius geometry
• 55 ton/m load capacity
• Suitable for very acute-angle bending
• Suitable for pre-bending
• Suitable for multi-stage forming
• Suitable for hemming preparation
• Increased forming clearance compared with smaller V-openings
• Custom V-openings available
• Custom die angles available
• Custom effective heights available
• Custom edge geometry available
• Custom lengths and segmentation available
• Custom lower-die mounting interfaces available

Technical Specifications

Typical Applications

This V16 30° single-V lower die is suitable for:

• Very acute-angle sheet metal bending
• Pre-bending operations
• Multi-stage press brake forming
• Hemming preparation
• Precision flange bending
• Components requiring acute intermediate forming angles
• Stainless steel sheet components
• Mild steel sheet components
• Electrical cabinet parts
• Sheet metal enclosures
• Machinery components
• Customized metal forming applications

The appropriate tooling configuration should be selected according to the material grade, sheet thickness, required bend angle, inside radius, flange dimensions and required bending force.

Standard & Custom Options

The V16 30° lower die shown on this page represents one typical configuration only and does not limit WYS Machinery's manufacturing range.

The following specifications can be customized:

• V-opening
• die angle
• overall height
• effective height
• body width
• load-bearing section width
• radius geometry
• edge dimensions
• tool length
• segmentation
• load capacity
• bottom mounting profile
• positioning structure
• clamping interface

Single-V, double-V, multi-V and other customized lower die structures are also available.

Compatible Press Brake Tooling Systems

WYS Machinery can manufacture lower dies for different press brake brands, tooling standards and clamping systems.

Available configurations include:

TRUMPF Type, WILA Type, LVD Type, Bystronic Type, Amada / Promecam Type, European Type and other customized press brake tooling systems.

The mounting structure shown in the drawing is only one available configuration.

The bottom mounting interface, positioning geometry, height, width and die cross-section can all be adapted according to the customer's press brake.

Customers can provide a machine model, existing tooling drawing, tooling cross-section, tooling sample or workpiece drawing for technical evaluation.

Custom V-Opening, Angle and Edge Geometry

The V16 opening and 30° die angle shown here are one available specification rather than fixed limitations.

Different V-openings and die angles can be manufactured according to:

• Sheet thickness
• Material grade
• Required bending angle
• Inside bending radius
• Minimum flange dimension
• Material springback
• Required bending force
• Press brake configuration

The radius, shoulder geometry, edge dimensions and supporting body profile can also be customized according to the application.

Custom Press Brake Tooling Design Service

Customers who do not already know the required tooling specification can provide their workpiece drawing, sheet material, material thickness, required bending angle and press brake model.

Our engineering team can evaluate the forming requirement and recommend an appropriate tooling configuration.

The lower die can then be manufactured with the required V-opening, angle, height, effective height, width, radius, tool length and mounting structure.

Why Choose WYS Machinery

WYS Machinery manufactures standard and customized press brake punches, lower dies and sheet metal bending tooling for different forming requirements.

Our lower tooling capabilities include:

• Single-V lower dies
• Double-V dies
• Multi-V dies
• 30° acute-angle dies
• Custom-angle lower dies
• Small and medium V-opening dies
• Segmented tooling
• Customized effective heights
• Customized load-bearing sections
• Special lower-tool profiles
• Custom mounting interfaces
• Replacement tooling for different press brake systems
• Tooling designed according to customer workpiece drawings

This enables customers to obtain tooling matched to both their machine interface and actual sheet metal forming requirements.
