V16 88° Single-V Press Brake Lower Die for Precision Sheet Metal Bending

This V16 press brake lower die is designed with a single-V structure for stable and accurate sheet metal bending.

The illustrated model features a 16 mm V-opening, 88° die angle, 90 mm overall height and 21 mm main body width, with a rated load capacity of 100 ton/m.

The V16 opening provides a practical lower-tool geometry for a wide range of general sheet metal bending applications, while the 88° V-groove offers additional flexibility for air bending operations where material springback needs to be considered.

Its single-V design provides a straightforward and rigid bending surface, making the tool suitable for repeated CNC press brake forming operations.

Flexible Effective Tool Height

The illustrated die has an overall height of 90 mm, while the effective working height can be adapted according to the customer's press brake configuration.

Typical options include:

70 mm, 75 mm or other customized effective heights.

This allows the lower die to be matched with different punch heights, tooling combinations, clamping systems and machine configurations.

V16 Single-V Die Geometry

The die combines a 16 mm V-opening with a 21 mm main body width, providing additional body support while maintaining a compact lower-tool profile.

The illustrated configuration includes:

• 16 mm V-opening
• 88° die angle
• 21 mm main body width
• 14 mm bottom mounting width
• Approx. R2 shoulder radius
• 100 ton/m load capacity

This geometry provides a reliable solution for precision air bending and general sheet metal fabrication within the specified load capacity.

Key Features

• Single-V lower die design
• V16 / 16 mm V-opening
• 88° die angle
• 90 mm overall height
• 70 mm, 75 mm or customized effective height
• 21 mm main body width
• 14 mm bottom mounting width
• 100 ton/m load capacity
• Approx. R2 shoulder radius
• Precision-machined V-groove
• Stable lower-tool structure
• Suitable for controlled air bending
• Custom tool lengths available
• Segmented tooling available
• Custom mounting and positioning structures available

Technical Specifications

Typical Applications

This V16 88° single-V lower die is suitable for a wide range of sheet metal bending operations, including:

• Precision air bending
• General sheet metal fabrication
• Thin and medium-gauge sheet bending
• Electrical cabinet manufacturing
• Control panel production
• Sheet metal enclosure fabrication
• Machinery covers and housings
• Stainless steel component bending
• Mild steel fabrication
• Precision flange forming
• General CNC press brake applications

The actual die configuration should be selected according to the material type, sheet thickness, required bending angle, inside radius, flange length and bending tonnage.

Standard & Custom Options

The V16 lower die shown on this page represents one typical single-V configuration only.

WYS Machinery can manufacture press brake lower dies with customized:

• V-openings
• die angles
• overall heights
• effective heights
• body widths
• shoulder radii
• bottom mounting profiles
• tool lengths
• segmented lengths
• load capacities
• positioning structures
• clamping interfaces

Different V-openings such as V6, V8, V10, V12, V14, V16, V20 and other custom sizes can be manufactured according to the actual sheet thickness and bending requirements.

Single-V, multi-V and other customized lower die structures are also available.

Compatible Press Brake Tooling Systems

WYS Machinery can manufacture customized lower dies for different press brake brands, tooling standards and clamping systems.

Available configurations include:

TRUMPF Type, WILA Type, LVD Type, Bystronic Type, Amada / Promecam Type, European Type and other customized press brake tooling systems.

The die height, effective working height, bottom mounting profile and positioning structure can all be adapted to the customer's machine and tooling system.

Customers can provide a machine model, tooling drawing, lower die cross-section, existing sample or workpiece drawing for technical evaluation.

Custom Press Brake Die Design Service

For applications where the suitable V-opening, tooling height or mounting structure has not yet been determined, customers can provide:

workpiece drawing, material type, sheet thickness, required bending angle and press brake model.

Our engineering team can recommend an appropriate lower die configuration according to the actual bending requirement.

The V-opening, angle, overall height, effective height, width, radius, tool length and mounting structure can all be customized.

Why Choose WYS Machinery

WYS Machinery manufactures both standard and customized press brake dies, punches and sheet metal bending tooling.

Our lower tooling capabilities include:

• Single-V dies
• Multi-V dies
• Narrow V-dies
• Heavy-duty lower dies
• Segmented dies
• Customized tooling heights
• Special lower-tool profiles
• Custom mounting interfaces
• Replacement dies for different press brake systems
• Tooling design according to customer workpiece drawings

Customers can obtain both standard replacement tooling and customized bending solutions according to their actual production requirements.
