V18 88° Single-V Press Brake Lower Die for Precision Bending

This V18 press brake lower die is designed with a single-V structure for stable and accurate sheet metal bending.

The illustrated model features an 18 mm V-opening, 88° die angle, 90 mm overall height and 22 mm main body width, with a rated load capacity of 100 ton/m.

The V18 opening provides a practical solution for a wide range of sheet metal bending applications, especially where a larger V-opening than V14 or V16 is required. The 88° groove geometry is suitable for controlled air bending and provides additional flexibility when compensating for material springback.

The single-V structure offers a simple, stable and durable lower-tool configuration for repeated CNC press brake forming operations.

Flexible Effective Tool Height

The total tool height of the illustrated die is 90 mm, while the effective working height can be customized according to the customer's machine and tooling setup.

Typical options include:

70 mm, 75 mm or other customized effective heights.

This allows the die to be adapted to different punch heights, press brake daylight, tooling combinations and clamping systems.

V18 Single-V Die Geometry

The die combines an 18 mm V-opening with a 22 mm main body width, providing a robust lower-tool profile for reliable bending performance.

The illustrated configuration includes:

• 18 mm V-opening
• 88° die angle
• 22 mm main body width
• 14 mm bottom mounting width
• Approx. R2.5 shoulder radius
• 100 ton/m load capacity

This geometry is suitable for precision air bending and general sheet metal fabrication within the rated tonnage.

Key Features

• Single-V lower die design
• V18 / 18 mm V-opening
• 88° die angle
• 90 mm overall height
• 70 mm, 75 mm or customized effective height
• 22 mm main body width
• 14 mm bottom mounting width
• 100 ton/m load capacity
• Approx. R2.5 shoulder radius
• Precision-machined V-groove
• Stable and durable lower-tool structure
• Suitable for controlled air bending
• Custom tool lengths available
• Segmented tooling available
• Custom mounting and positioning structures available

Technical Specifications

Typical Applications

This V18 88° single-V lower die is suitable for a wide range of sheet metal forming applications, including:

• Precision air bending
• General sheet metal fabrication
• Thin and medium-gauge sheet bending
• Electrical cabinet manufacturing
• Control panel production
• Sheet metal enclosure fabrication
• Machinery covers and housings
• Stainless steel component bending
• Mild steel fabrication
• Precision flange forming
• General CNC press brake applications

The actual die specification should be selected according to the material type, sheet thickness, required bending angle, inside radius, flange length and bending tonnage.

Standard & Custom Options

The V18 lower die shown on this page represents one typical single-V configuration only.

WYS Machinery can manufacture press brake lower dies with customized:

• V-openings
• die angles
• overall heights
• effective heights
• body widths
• shoulder radii
• bottom mounting profiles
• tool lengths
• segmented lengths
• load capacities
• positioning structures
• clamping interfaces

Different V-openings such as V8, V10, V12, V14, V16, V18, V20 and other custom sizes can be manufactured according to the actual sheet thickness and bending requirements.

Single-V, multi-V and other customized lower die structures are also available.

Compatible Press Brake Tooling Systems

WYS Machinery can manufacture customized lower dies for different press brake brands, tooling standards and clamping systems.

Available configurations include:

TRUMPF Type, WILA Type, LVD Type, Bystronic Type, Amada / Promecam Type, European Type and other customized press brake tooling systems.

The die height, effective working height, bottom mounting profile and positioning structure can all be adapted to the customer's machine and tooling system.

Customers can provide a machine model, tooling drawing, lower die cross-section, existing sample or workpiece drawing for technical evaluation.

Custom Press Brake Die Design Service

For applications where the suitable V-opening, die angle or tooling height has not yet been determined, customers can provide:

workpiece drawing, material type, sheet thickness, required bending angle and press brake model.

Our engineering team can recommend an appropriate lower die configuration according to the actual bending requirement.

The V-opening, angle, overall height, effective height, width, radius, tool length and mounting structure can all be customized.

Why Choose WYS Machinery

WYS Machinery manufactures both standard and customized press brake dies, punches and sheet metal bending tooling.

Our lower tooling capabilities include:

• Single-V dies
• Multi-V dies
• Narrow V-dies
• Heavy-duty lower dies
• Segmented dies
• Customized tooling heights
• Special lower-tool profiles
• Custom mounting interfaces
• Replacement dies for different press brake systems
• Tooling design according to customer workpiece drawings

Customers can obtain both standard replacement tooling and customized bending solutions according to their actual production requirements.
