V80 60° Stepped-Base Single-V Press Brake Lower Die – H110 × W110 mm, 100 Ton/m
This V80 60° stepped-base single-V press brake lower die features an 80 mm V-opening, 60° die angle, 110 mm overall height and 110 mm main body width, with a 60 mm bottom mounting base and 20 mm stepped section. The rated load capacity is 100 ton/m. Unlike conventional plug-in single-V lower dies, this model uses a stepped-base mounting structure rather than a narrow plug-in shank. The V-opening, die angle, overall height, body width, bottom base dimensions, groove radii, tool length and mounting interface can all be customized according to the customer's press brake and bending requirements.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
V80 60° Stepped-Base Single-V Press Brake Lower Die
This V80 60° press brake lower die combines a large 80 mm V-opening with a 60° acute-angle single-V groove and a stepped mounting base, providing a robust lower-tool configuration for sheet metal bending applications requiring both acute-angle forming capability and increased forming clearance.
The illustrated configuration features:
V-Opening: V80 / 80 mm
Die Angle: 60°
Overall Height: 110 mm
Main Body Width: 110 mm
Bottom Base Width: 60 mm
Stepped Section Height: 20 mm
Shoulder Radius: R8
V-Bottom Radius: R8
Rated Load Capacity: 100 ton/m
The 110 mm main tool body transitions to a 60 mm stepped mounting base, which is structurally different from conventional plug-in lower dies that use a narrow bottom shank.
The tooling shown represents one available configuration only. WYS Machinery can manufacture different V-openings, angles, heights, widths, radii, tool lengths and mounting structures according to customer requirements.
60° V-Groove for Acute-Angle Bending
The 60° single-V groove provides more angular clearance than conventional 85°, 88° or 90° lower dies.
This geometry is suitable for applications such as:
- Acute-angle air bending
- Pre-bending
- Multi-stage forming
- Intermediate-angle forming
- Precision flange bending
- Forming requiring springback allowance
- Customized sheet metal profiles
The actual bending result depends on the complete tooling combination and forming conditions, including the material grade, sheet thickness, punch geometry, V-opening, springback, required inside radius, flange dimensions and bending force.
V80 Opening for Large Forming Clearance
The 80 mm V-opening provides a large working zone and substantial clearance around the workpiece during bending.
Compared with smaller V-opening lower dies, the V80 configuration provides:
- Greater forming clearance
- A broader bending zone
- Increased space around the workpiece
- Suitability for larger expected bend radii
- More flexibility for larger sheet and flange geometry
The correct V-opening should always be selected according to the material type, sheet thickness, desired bend radius, flange size and bending-force requirements.
Stepped-Base Mounting Structure
A key characteristic of this lower die is the stepped-base mounting profile.
The illustrated dimensions are:
Main Body Width: 110 mm
Bottom Base Width: 60 mm
Step Height: 20 mm
This differs from a plug-in lower die, where a relatively narrow bottom shank is inserted into a corresponding lower-die holder.
The stepped-base design provides a wider working body combined with a defined mounting section underneath.
The body width, base width, step height, positioning geometry and complete mounting cross-section can all be customized according to the customer's machine and lower-die holder.
R8 Shoulder and V-Bottom Radii
The illustrated V80 groove uses:
Shoulder Radius: R8
V-Bottom Radius: R8
These radii form part of the working groove profile and can also be customized according to the V-opening, sheet thickness, material and required forming geometry.
Key Features
- V80 / 80 mm V-opening
- 60° acute-angle single-V groove
- 110 mm overall height
- 110 mm main body width
- 60 mm bottom base width
- 20 mm stepped mounting section
- R8 shoulder radius
- R8 V-bottom radius
- 100 ton/m rated load capacity
- Stepped-base mounting structure
- Different from plug-in lower dies
- Large forming clearance
- Suitable for acute-angle bending
- Suitable for pre-bending and multi-stage forming
- Custom V-opening
- Custom die angle
- Custom groove radii
- Custom body and base dimensions
- Custom step geometry
- Custom tool length and segmentation
- Custom mounting interface
Technical Specifications
| Specification | Value |
|---|---|
| Product Type | Stepped-Base Single-V Press Brake Lower Die |
| Die Structure | Single-V |
| V-Opening | V80 / 80 mm |
| Die Angle | 60° / Customized |
| Overall Height | 110 mm / Customized |
| Main Body Width | 110 mm / Customized |
| Bottom Base Width | 60 mm / Customized |
| Stepped Section Height | 20 mm / Customized |
| Shoulder Radius | R8 / Customized |
| V-Bottom Radius | R8 / Customized |
| Load Capacity | 100 ton/m |
| Mounting Structure | Stepped Base |
| Tool Length | Standard / Customized |
| Segmentation | Available |
| Mounting Interface | Stepped Base / Customized |
| Main Application | Acute-Angle Bending / Large V-Opening Air Bending |
Typical Applications
This V80 60° stepped-base single-V press brake lower die is suitable for:
- Acute-angle sheet metal bending
- Large V-opening air bending
- Pre-bending operations
- Multi-stage press brake forming
- Intermediate-angle forming
- Precision flange bending
- Applications requiring increased forming clearance
- Stainless steel sheet bending
- Mild steel sheet bending
- Electrical cabinet components
- Industrial machinery components
- Structural sheet metal parts
- Customized sheet metal profiles
- Applications requiring stepped-base lower tooling
The appropriate tooling specification should be selected according to the material grade, sheet thickness, required bend angle, inside radius, flange dimensions and required bending force.
Standard & Custom Options
The V80 60° stepped-base lower die shown on this page represents one available configuration only.
WYS Machinery can customize:
- V-opening
- die angle
- overall height
- main body width
- bottom base width
- stepped section height
- shoulder radius
- V-bottom radius
- edge geometry
- tool length
- segmented length
- load capacity
- bottom mounting profile
- positioning structure
- clamping interface
In addition to stepped-base single-V dies, WYS Machinery can manufacture plug-in single-V dies, full-width wide-base dies, T-type single-V dies, double-V dies, multi-V dies and other customized lower-die structures.
Compatible Press Brake Tooling Systems
WYS Machinery can manufacture lower dies for different press brake brands, tooling standards and clamping systems.
Available configurations include:
TRUMPF Type, WILA Type, LVD Type, Bystronic Type, Amada / Promecam Type, European Type and other customized press brake tooling systems.
The stepped-base structure shown here is only one available mounting configuration.
The bottom mounting profile, base width, step height, overall height, body width and complete die cross-section can all be adapted according to the customer's press brake.
Customers can provide a machine model, existing tooling drawing, lower-die cross-section, die-holder dimensions, tooling sample or workpiece drawing for technical evaluation.
Custom V-Opening and Die Angle
The V80 opening and 60° groove are not fixed limitations.
Different V-openings and die angles can be manufactured according to:
- Material grade
- Sheet thickness
- Required bending angle
- Desired inside radius
- Minimum flange dimension
- Material springback
- Required forming clearance
- Required bending force
- Press brake configuration
This allows the lower die to be designed around the customer's actual workpiece rather than limiting the application to a fixed catalog profile.
Custom Mounting Structure
Single-V press brake lower dies can use different mounting structures.
WYS Machinery can manufacture:
Plug-in Mounting Structure
Full-Width Wide-Base Structure
Stepped-Base Structure
T-Type Structure
Other Customized Lower-Die Interfaces
The appropriate mounting configuration can be designed according to the customer's lower-die holder, press brake and existing tooling system.
Custom Press Brake Tooling Design Service
Customers can provide their workpiece drawings, material grade, sheet thickness, required bend angle, desired radius, press brake model and existing tooling information.
Our engineering team can evaluate the forming requirement and recommend an appropriate lower-die configuration.
The tooling can then be manufactured with the required V-opening, angle, height, body width, base dimensions, groove radii, tool length and mounting structure.
Why Choose WYS Machinery
WYS Machinery manufactures standard and customized press brake punches, lower dies and sheet metal bending tooling for different sheet metal forming requirements.
Our lower-tooling capabilities include:
- Stepped-base single-V lower dies
- Wide-base single-V lower dies
- Plug-in single-V lower dies
- T-type single-V lower dies
- Double-V dies
- Multi-V dies
- Acute-angle lower dies
- Large V-opening lower dies
- Custom-angle lower dies
- Customized V-openings
- Customized tooling heights
- Customized base structures
- Customized groove radii
- Segmented tooling
- Special lower-tool profiles
- Custom mounting interfaces
- Replacement tooling for different press brake systems
- Tooling manufactured according to customer drawings
The products displayed on our website demonstrate available tooling structures and manufacturing capabilities, while final dimensions and mounting arrangements can be adapted to the customer's actual production requirements.
