A Station Downward Center Point Marking Tool
A Station downward center point marking tool for thick turret punch presses, designed to create a controlled locating dimple without punching through the sheet. Ideal for drill and tapping location, bending reference marks, assembly positioning and sheet metal identification.
Please add the quotation and send it to us and get in touch with us immediately
- Global service 24/7
- Lowest price for all products
- Best quality with Production Process
- After-Sale Warranty
- Technical Support
Description
This A Station downward center point marking tool creates a controlled locating dimple on the top surface of sheet metal without punching through the material. The corresponding underside forms a small raised feature, providing a clear and repeatable reference point for subsequent operations.
It is commonly used for drill and tapping location, bending reference marks, assembly and welding positioning, and part identification. Marking diameter, depth and tool geometry can be customized according to the material thickness and application requirements.
WYS Machinery can manufacture thick turret and thin turret versions in A, B, C, D and E station sizes. TRUMPF and Murata Wiedemann type structures are also available for different punch press systems.
Key Features
- Downward forming design for visible top-side locating marks
- Creates a locating dimple without penetrating the sheet
- Suitable for drilling and tapping pre-location
- Provides reference points for bending, assembly and welding
- Marking diameter and depth can be customized
- Thick turret and thin turret configurations available
- A, B, C, D and E station sizes available
- TRUMPF and Murata Wiedemann type structures available
- Custom manufacturing according to drawings and application requirements
Technical Specifications
| Item | Specification |
|---|---|
| Tool Type | Center Point Marking / Forming Tool |
| Tooling System | Thick Turret |
| Station | A Station |
| Forming Direction | Downward |
| Sheet Penetration | Non-Piercing |
| Top-Side Result | Locating Dimple |
| Underside Result | Small Raised Feature |
| Mark Diameter | Customizable |
| Mark Depth | Customizable |
| Other Station Sizes | B / C / D / E Available |
| Other Tooling Systems | Thin Turret / TRUMPF / Murata Wiedemann Types |
| Customization | Drawing / Material / Application Based |
Typical Applications
- Drill hole pre-location
- Tapping hole pre-location
- Bending reference points
- Assembly positioning
- Welding reference points
- Center location marking
- Part orientation and identification
- Sheet metal fabrication reference marks
Manufacturing Quality
Precision machining helps maintain consistent mark position, depth and forming geometry. Tool dimensions and forming depth can be engineered according to sheet thickness, material properties and the required locating mark while avoiding unnecessary penetration of the workpiece.
Standard & Custom
The tooling shown is one example of an A Station downward center point marking solution and does not represent a limitation on available sizes or configurations.
WYS Machinery can manufacture center point marking tools according to customer drawings, sheet material and application requirements. Mark diameter, depth and forming geometry can be customized. Thick turret and thin turret configurations are available in A, B, C, D and E station sizes, with TRUMPF and Murata Wiedemann type structures also available.
